SCI(史博森）EMC/EMI/RFI滤波器件 、Ｄ型滤波连接器、圆型滤波连接器、 航空连接头、ＤＢ９／15／２５滤波连接器、 带通滤波器、穿心电容、电源滤波器、陶瓷管状电容、滤波阵列板；
滤波转接器高性能，常用型号：56-705-003 56-715-003 56-725-003
56-402-001 500VDC/1000VAC 5A D-Sub 9 pin See Pg. 133
56-412-001 500VDC/1000VAC 5A D-Sub 15 pin See Pg. 133
56-422-001 500VDC/1000VAC 5A D-Sub 25 pin See Pg. 133
56-404-001 500VDC/1000VAC 5A D-Sub 9 socket See Pg. 134
56-414-001 500VDC/1000VAC 5A D-Sub 15 socket See Pg. 134
56-424-001 500VDC/1000VAC 5A D-Sub 25 socket See Pg. 134
56-414-001-HD 500VDC/1000VAC 5A Hi-Density 15 socket See Pg. 134
56-407-001 500VDC/1000VAC 5A D-Sub 9 pin See Pg. 135
56-417-001 500VDC/1000VAC 5A D-Sub 15 pin See Pg. 135
56-427-001 500VDC/1000VAC 5A D-Sub 25 pin See Pg. 135
56-403-001 500VDC/1000VAC 5A D-Sub 9 socket See Pg. 136
56-413-001 500VDC/1000VAC 5A D-Sub 15 socket See Pg. 136
56-423-001 500VDC/1000VAC 5A D-Sub 25 socket See Pg. 136
56-102-002 9 size Pin to right angle 100pF See Pg. 138-140
56-102-003 9 size Pin to right angle 220pF See Pg. 138-140
56-102-004 9 size Pin to right angle 470pF See Pg. 138-140
56-102-005 9 size Pin to right angle 820pF See Pg. 138-140
56-102-006 9 size Pin to right angle 1500pF See Pg. 138-140
56-104-002 9 size Socket to right angle 100pF See Pg. 138-140
56-104-003 9 size Socket to right angle 220pF See Pg. 138-140
56-104-004 9 size Socket to right angle 470pF See Pg. 138-140
56-104-005 9 size Socket to right angle 820pF See Pg. 138-140
56-104-006 9 size Socket to right angle 1500pF See Pg. 138-140
56-112-002 15 size Pin to right angle 100pF See Pg. 138-140
56-112-003 15 size Pin to right angle 220pF See Pg. 138-140
56-112-004 15 size Pin to right angle 470pF See Pg. 138-140
56-112-005 15 size Pin to right angle 820pF See Pg. 138-140
56-112-006 15 size Pin to right angle 1500pF See Pg. 138-140
56-114-002 15 size Socket to right angle 100pF See Pg. 138-140
56-114-003 15 size Socket to right angle 220pF See Pg. 138-140
56-114-004 15 size Socket to right angle 470pF See Pg. 138-140
56-114-005 15 size Socket to right angle 820pF See Pg. 138-140
56-114-006 15 size Socket to right angle 1500pF See Pg. 138-140
56-122-002 25 size Pin to right angle 100pF See Pg. 138-140
56-122-003 25 size Pin to right angle 220pF See Pg. 138-140
1图，型号：56-725-003
2图，型号：56-715-003
3图，型号：56-705-003
|
